Ball Joint Damper with Washer
Ball Joint Damper with Washer for OEM damper applications. Review mounting, dimensions, operating conditions, and custom production with LX Gas Spring.
Product Overview
Ball Joint Damper with Washer is intended for damping mechanisms that need angular articulation at the mounting point and controlled axial spacing. For an OEM specification, the product should be reviewed as part of the complete mechanism rather than selected from appearance alone. Check ball size, socket articulation, washer position, fastener stack, alignment, and available swing clearance. LX Gas Spring can then match force or damping behavior, stroke, installed length, material, and end connections to the drawing or sample.
Exact force, stroke, length, and fitting dimensions should be confirmed from your drawing, sample, or installation measurements before production.
Key Features
- Application focus: damping mechanisms that need angular articulation at the mounting point and controlled axial spacing.
- Interface review: Check ball size, socket articulation, washer position, fastener stack, alignment, and available swing clearance.
- Controlled damping for lids, covers, compartments, and soft-motion assemblies.
- Helps reduce impact, noise, and uncontrolled closing in mechanical systems.
Technical Specifications / Product Details
- Product family: Damper
- Product-specific use: damping mechanisms that need angular articulation at the mounting point and controlled axial spacing
- Mounting and control check: Check ball size, socket articulation, washer position, fastener stack, alignment, and available swing clearance.
- End fitting reference: confirmed from drawing or sample
- Force or damping requirement: confirmed from load, geometry, motion direction, and operating conditions
- Stroke and installed length: checked at both end positions before sample approval
What to Confirm Before Ordering
- Check ball size, socket articulation, washer position, fastener stack, alignment, and available swing clearance.
- Decide whether the application needs lift support, damping, or both before selecting a component.
- Describe the direction of motion, moving weight, stroke, desired speed, and the point where impact must be reduced.
- Send a short video when damping feel is important because motion speed is difficult to judge from dimensions alone.
- Check installed length and end fittings through the full travel to avoid binding.
Common Specification Risks
- An incorrect washer stack can restrict articulation or shift the damper out of alignment.
- A damper selected as if it were a lift gas spring may not hold the lid or cover open.
- Incorrect damping direction can control the wrong part of the movement.
- Too much damping can make the mechanism feel stiff or slow during normal use.
- Poor mounting alignment can cause side load and inconsistent damping behavior.
OEM Manufacturing Support
- Damping direction, stroke, installed length, fittings, and motion feel can be reviewed from samples or application videos.
- RV, toolbox, waste-bin, furniture, and equipment-cover projects often need sample testing for user feel.
- Production details should record the damping requirement, orientation, end fitting style, packaging, and replacement reference.
Common Applications
Customization Options
- Damping direction and motion feel reviewed according to the mechanism.
- Stroke and installed length matched to available space.
- Ball joint, blade end, washer, or bracket-style connection options.
- Sample-based matching when replacing an existing camper or compartment damper.
How to Request a Quote
Send the following information with your drawing, sample photo, or application sketch for a practical OEM gas spring recommendation.
- Ball stud size, washer stack drawing, articulation angle, and motion video
- Application and installation photos
- Panel, lid, or moving part weight
- Stroke, extended length, and compressed length
- Mounting point distance and opening angle
- Required force or sample part number if available
- End fitting type, quantity, and working environment
Related Resources
Related Products in This Family
Product FAQ
Is Ball Joint Damper with Washer used for lifting or damping?
It is primarily used for damping and controlled motion. If lift assistance is also required, LX Gas Spring can review whether a gas spring, damper, or combined solution is more suitable.
What should be sent for a damper quotation?
Send application photos, installed length, stroke, mounting type, lid weight if known, desired motion speed, quantity, and any sample part photos.
Can this damper be matched to camper or RV compartment hardware?
Yes. Photos, dimensions, and sample details help confirm a practical replacement or OEM damping option.
